YL-BGE SERIES 3,5” SUBMERSIBLE ELECTRIC PUMPS
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Material
| REF.N. | PART | MATERIAL | STANDARD |
|---|---|---|---|
| 1 | Lower support | Precision cast stainless steel & Cast iron | AISI 201 & ASTM 200A |
| 2 | Coupling | Stainless steel | AISI 304 |
| 3 | Stage housing | ABS | …… |
| 4 | Impeller | ABS | …… |
| 5 | Diffuser | ABS | …… |
| 6 | Outer sleeve | Stainless steel | AISI 201 |
| 7 | Bush bearing | TPU | …… |
| 8 | Sand protection cover | ABS | …… |
| 9 | Pin | Stainless steel | AISI 304 |
| 10 | Delivery port | Precision cast stainless & Cast iron | AISI 201 & ASTM 200A |
| 11 | Non-return valve | PC & ABS | …… |
| 12 | O-ring | NBR | …… |
| 13 | Bushing | Stainless steel | AISI 304 |
| 14 | Intermediate support | ABS | …… |
| 15 | Cable guard | Stainless steel | AISI 430 |
| 16 | Shaft | Stainless steel | AISI 410 |
| 17 | Screw | Stainless steel | AISI 201 |
| 18 | Filter | Stainless steel | AISI 201 |
Specification
| PUMP TYPE | No.OF STAGES | kW | Hp | Q=DELIVERY l/min ｜ 0 17 33 50 67 m³/h ｜ 0 1 2 3 4 H=TOTAL HEAD METERS COLUMN OF WATER |
||||
|---|---|---|---|---|---|---|---|---|
| 0 | 17 | 33 | 50 | 67 | ||||
| YL2BGE03C(G) | 8 | 0,37 | 0,5 | 48 | 47 | 42 | 39 | 26 |
| YL2BGE05C(G) | 10 | 0,55 | 0,75 | 60 | 59 | 55 | 49 | 33 |
| YL2BGE07C(G) | 12 | 0,75 | 1 | 72 | 71 | 66 | 57 | 40 |
| YL2BGE09C(G) | 15 | 0,95 | 1,3 | 89 | 88 | 82 | 70 | 49 |
| YL2BGE11C(G) | 17 | 1,1 | 1,5 | 102 | 100 | 93 | 80 | 56 |
| YL2BGE15C(G) | 22 | 1,5 | 2 | 131 | 127 | 120 | 99 | 67 |
| YL2BGE17C(G) | 27 | 1,7 | 2,3 | 160 | 153 | 140 | 115 | 78 |
