CBS SERIES THREE-PHASE ELECTRIC PANELS (9,2~15kW)
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Material
- Supply voltage: 3 x 380 V ±10%.
- Frequency: 50/60 Hz.
- Power: 9,2 to 15 kW.
- Protection class: IP54.
- Ambient temperature: 0℃ to +40℃.
- Relative humidity: ≤ 90%.
- Altitude: ≤ 2000 m.
Specification
| PANEL TYPE | VOLTAGE V | POWER | CURRENT A | A mm | B mm | C mm | WEIGHT kg | |
|---|---|---|---|---|---|---|---|---|
| kW | Hp | |||||||
| CBS92T | 380 | 9,2 | 12,5 | 22,4 | 195 | 270 | 112 | 1,8 |
| CBS110T | 380 | 11 | 15 | 26,5 | 195 | 270 | 112 | 1,8 |
| CBS130T | 380 | 13 | 17,5 | 30,9 | 195 | 270 | 112 | 1,8 |
| CBS150T | 380 | 15 | 20 | 36,0 | 195 | 270 | 112 | 1,8 |
